46 PRO X
System Inputs and Outputs
Control Surface Input Connector 3 pin XLR balanced
AD Converter 24 bit, 96 kHz and 128 X oversampling
Control Surface Analogue Outputs Connector 3 pin XLR balanced
DA Converter 24 bit, 96 kHz and 128 X oversampling
MIDI Connector In, Out and Thru on 5 pin DIN
Control Surface Digital System Inputs and Outputs
System Connector 3 X AES50 (24 channels of bidirectional digital audio) on EtherCON XLR
Word Clock IN Connector BNC
Word Clock OUT Connector BNC
AES3 Sync IN Connector 3 pin XLR
AES3 Sync OUT Connector 3 pin XLR
Control Surface Analogue Audio System Inputs
Connector 3 pin XLR balanced
AD Converter 24 bit, 96 kHz and 128 times over sampling
Talkback Connector 3 pin XLR balanced line
Talk Connector 3 pin XLR balanced mic with 48 V phantom
Control Surface Analogue Audio System Outputs
Connector 3 pin XLR balanced
DA Converter 24 bit, 96 kHz and 128 times over sampling
Monitor Connector 3 pin XLR balanced line
Talk Connector 3 in XLR balanced line
Headphone Connector ¼ inch Jack (stereo)
Control Surface Digital Audio System Inputs and Outputs
Input Connector AES3 (two channels of digital audio) on 3-pin XLR
Sample Rates Accepts any frequency 32 kHz – 96 kHz
Bypass Sample rate converter can be bypassed
Output Connector AES3 (two channels of digital audio) on 3-pin XLR
Sample Rate 48 K, 96 K or auto tracking to Inputs
Bypass Sample rate converter can be bypassed
Control Surface Digital Audio System Inputs and Outputs
Word length 16, 20 or 24 bit
Control Surface Control Data SystemInputsand Outputs
System Connector EtherCON XLR
Control Surface Misc Inputs and Outputs
Monitor Output Connector 3 row 15 pin D TYPE – analogue VGA
USB Host Connection USB 2.0 full speed (12.0 Mbs)
5 V, 1 A max load
