Midea MV5-X252W/V2GN1 User Manual

V5 X VRF 50/60Hz
201608 9
Part 1 - General Information
4 Combination Ratio
Table 1-4.1: Indoor and outdoor unit combination ratio limitations
Type
Minimum
combination ratio
Maximum combination ratio
Standard indoor
units only
Fresh air processing
units only
Fresh air processing units and
standard indoor units together
V5 X Series outdoor units
50%
130%
100%
100%
1
Notes:
1. When fresh air processing units are installed together with standard indoor units, the total capacity of the fresh air processing units must not exceed 30%
of the total capacity of the outdoor units and the combination ratio must not exceed 100%.
Table 1-4.2: Combinations of indoor and outdoor units
Outdoor unit capacity
Sum of capacity indexes of
connected indoor units
(standard indoor units only)
Sum of capacity indexes of connected
indoor units (fresh air processing units and
standard indoor units together)
Maximum number of
connected indoor units
kW
HP
Capacity index
25.2
8
252
126 to 327.6
126 to 252
13
28.0
10
280
140 to 364
140 to 280
16
33.5
12
335
167.5 to 435.5
167.5 to 335
20
40.0
14
400
200 to 520
200 to 400
23
45.0
16
450
225 to 585
225 to 450
26
50.0
18
500
250 to 650
250 to 500
29
56.0
20
560
280 to 728
280 to 560
33
61.5
22
615
307.5 to 799.5
307.5 to 615
36
67.0
24
670
335 to 871
335 to 670
39
73.0
26
730
365 to 949
365 to 730
43
78.0
28
780
390 to 1014
390 to 780
46
84.0
30
840
420 to 1092
420 to 840
50
89.5
32
895
447.5 to 1163.5
447.5 to 895
53
95.0
34
950
475 to 1235
475 to 950
56
100.0
36
1000
500 to 1300
500 to 1000
59
106.5
38
1065
532.5 to 1384.5
532.5 to 1065
63
111.5
40
1115
557.5 to 1449.5
557.5 to 1115
64
117.5
42
1175
587.5 to 1527.5
587.5 to 1175
123.0
44
1230
615 to 1599
615 to 1230
128.5
46
1285
642.5 to 1670.5
642.5 to 1285
134.5
48
1345
672.5 to 1748.5
672.5 to 1345
139.5
50
1395
697.5 to 1813.5
697.5 to 1395
145.5
52
1455
727.5 to 1891.5
727.5 to 1455
151.0
54
1510
755 to 1963
755 to 1510
156.5
56
1565
782.5 to 2034.5
782.5 to 1565
161.5
58
1615
807.5 to 2099.5
807.5 to 1615
168.0
60
1680
840 to 2184
840 to 1680
173.0
62
1730
865 to 2249
865 to 1730
179.0
64
1790
895 to 2327
895 to 1790
184.5
66
1845
922.5 to 2398.5
922.5 to 1845
190.0
68
1900
950 to 2470
950 to 1900
196.0
70
1960
980 to 2548
980 to 1960
201.0
72
2010
1005 to 2613
1005 to 2010
207.0
74
2070
1035 to 2691
1035 to 2070
212.5
76
2125
1062.5 to 2762.5
1062.5 to 2125
218.0
78
2180
1090 to 2834
1090 to 2180
223.0
80
2230
1115 to 2899
1115 to 2230
229.5
82
2295
1147.5 to 2983.5
1147.5 to 2295
234.5
84
2345
1172.5 to 3048.5
1172.5 to 2345
240.5
86
2405
1202.5 to 3126.5
1202.5 to 2405
246.0
88
2460
1230 to 3198
1230 to 2460
Combination ratio =
Sum of capacity indexes of the indoor units
Capacity index of the outdoor units
