Midea V5 X Series Service Manual
3 Outdoor Unit Combinations
Table 1-3.1: Outdoor unit combinations
System capacity
Number
of units
Modules
1
Outdoor branch joint kit
2
kW
HP
8
10
12
14
16
18
20
22
25.2
8
1
●
—
28.0
10
1
●
33.5
12
1
●
40.0
14
1
●
45.0
16
1
●
50.0
18
1
●
56.0
20
1
●
61.5
22
1
●
67.0
24
2
●●
FQZHW-02N1D
73.0
26
2
●
●
78.0
28
2
●
●
84.0
30
2
●
●
89.5
32
2
●
●
95.0
34
2
●
●
100.0
36
2
●●
106.5
38
2
●
●
111.5
40
2
●
●
117.5
42
2
●
●
123.0
44
2
●●
128.5
46
3
●●
●
FQZHW-03N1D
134.5
48
3
●
●
●
139.5
50
3
●
●
●
145.5
52
3
●
●
●
151.0
54
3
●
●●
156.5
56
3
●
●●
161.5
58
3
●●
●
168.0
60
3
●
●●
173.0
62
3
●
●●
179.0
64
3
●
●●
184.5
66
3
●●●
190.0
68
4
●●
●●
FQZHW-04N1D
196.0
70
4
●
●
●●
201.0
72
4
●
●
●●
207.0
74
4
●
●
●●
212.5
76
4
●
●●●
218.0
78
4
●
●●●
223.0
80
4
●●
●●
229.5
82
4
●
●●●
234.5
84
4
●
●●●
240.5
86
4
●
●●●
246.0
88
4
●●●●
Notes:
1. The combinations of units shown in the table are factory-recommended. Other combinations of units are also possible.
2. For systems with two or more outdoor units, outdoor branch joints (sold separately) are required.
