V5 X VRF 50/60Hz
24 201608
Midea V5 X Series Service Manual
4 Startup Control
4.1 Compressor Startup Delay Control
In initial startup control, compressor startup is delayed for 12 minutes in order to let the master unit search for the indoor
units addresses. In restart control (except in oil return operation and defrosting operation), compressor startup is delayed
such that a minimum of 7 minutes has elapsed since the compressor stopped, in order to prevent frequent compressor
on/off and to equalize the pressure within the refrigerant system.
4.2 Startup Control for Cooling Operation
Table 3-4.1: Component control during startup in cooling mode
Component
Wiring
diagram label
8-12HP
14-22HP
Control functions and states
Inverter compressor A
COMP(INV)
Controlled according to load requirement, operating
frequency increased by 1 step / sec
Inverter compressor B
COMP(INV1)
DC fan motor A
FANA
Fan speed
1
controlled according to discharge
pressure (P
c
):
At initial speed for 90 seconds.
Subsequently, P
c
checked every 10 seconds:
P
c
2.7MPa => 1 step increase.
P
c
2.1MPa => 1 step decrease.
DC fan motor B
FANB
Electronic expansion valve A
EXVA
Position (steps) from 0 (fully closed) to 480 (fully
open), controlled according to discharge
temperature
Electronic expansion valve B
EXVB
Four-way valve
ST1
Off
Solenoid valve (liquid refrigerant injection)
SV2
Off
Solenoid valve (oil balance)
SV4
Closed for 200 secs, open for 600 secs, then closed
Solenoid valve (fast defrosting)
SV5
Off
Solenoid valve (EXV bypass)
SV6
Open for 20 mins, then closed
Solenoid valve (indoor units bypass)
SV7
Off
Notes:
1. Refer to Table 3-5.3 in Part 3, 5.6 Outdoor Fan Control for more information on fan speed steps.
4.3 Startup Control for Heating Operation
Table 3-4.2: Component control during startup in heating mode
Component
Wiring
diagram label
8-12HP
14-22HP
Control functions and states
Inverter compressor A
COMP(INV)
Controlled according to load requirement, operating
frequency increased by 1 step / sec
Inverter compressor B
COMP(INV1)
DC fan motor A
FANA
Open once the four-way valve has opened,
controlled according to outdoor ambient
temperature and load requirement
DC fan motor B
FANB
Electronic expansion valve A
EXVA
Position (steps) from 0 (fully closed) to 480 (fully
open), controlled according to discharge superheat
Electronic expansion valve B
EXVB
Four-way valve
ST1
On
Solenoid valve (liquid refrigerant injection)
SV2
Off
Solenoid valve (oil balance)
SV4
Closed for 200 secs, open for 600 secs, then closed
Solenoid valve (fast defrosting)
SV5
Off
Solenoid valve (EXV bypass)
SV6
Off
Solenoid valve (indoor units bypass)
SV7
Off
Notes:
1. Refer to Table 3-5.3 in Part 3, 5.6 Outdoor Fan Control for more information on fan speed steps.
