Midea VRF Series User Manual

V6R VRF 50/60Hz
5
Part 1
-
General Information
1.1.2 Fresh air processing unit
Table 1-1.3: Fresh air processing unit capacity range
Capacity
12.5kW
14kW
20kW
25kW
28kW
Capacity index
125
140
200
250
280
Notes:
1. V6R series outdoor units are compatible with the 2nd generation DC Fresh air processing unit.
1.2 Heat recovery ventilator
Table 1-1.4: Heat recovery ventilator capacity range
Capacity
200m
3
/h
300m
3
/h
400m
3
/h
500m
3
/h
800m
3
/h
1000m
3
/h
1500m
3
/h
2000m
3
/h
Notes:
1. V6R series outdoor units are compatible with the DC type heat recovery ventilator.
1.3 High Temperature Hydro Module
Table 1-1.5: 1.3 High Temperature Hydro Module capacity range
Capacity
14kW
Capacity index
140
1.4 Outdoor Units
Table 1-1.6: Outdoor unit capacity range
Capacity
Model Name
Combination Type
8HP
MV6-R252WV2GN1
/
10HP
MV6-R280WV2GN1
/
12HP
MV6-R335WV2GN1
/
14HP
MV6-R400WV2GN1
/
16HP
MV6-R450WV2GN1
/
18HP
MV6-R500WV2GN1
/
20HP
MV6-R560WV2GN1
/
22HP
MV6-R615WV2GN1
12HP+10HP
24HP
MV6-R670WV2GN1
14HP+10HP
26HP
MV6-R730WV2GN1
14HP+12HP
28HP
MV6-R785WV2GN1
16HP+12HP
30HP
MV6-R850WV2GN1
18HP+12HP
32HP
MV6-R900WV2GN1
16HP+16HP
34HP
MV6-R950WV2GN1
18HP+16HP
36HP
MV6-R1015WV2GN1
18HP+18HP
38HP
MV6-R1065WV2GN1
20HP+18HP
40HP
MV6-R1120WV2GN1
20HP+20HP
42HP
MV6-R1175WV2GN1
16HP+14HP+12HP
44HP
MV6-R1230WV2GN1
16HP+16HP+12HP
46HP
MV6-R1285WV2GN1
16HP+16HP+14HP
48HP
MV6-R1345WV2GN1
16HP+16HP+16HP
50HP
MV6-R1400WV2GN1
18HP+16HP+16HP
52HP
MV6-R1460WV2GN1
18HP+18HP+16HP
54HP
MV6-R1515WV2GN1
18HP+18HP+18HP
56HP
MV6-R1570WV2GN1
20HP+18HP+18HP
58HP
MV6-R1635WV2GN1
20HP+20HP+18HP
60HP
MV6-R1685WV2GN1
20HP+20HP+20HP
Notes:
1. The combinations of units shown in the table are factory-recommended. Other combinations of units are also possible.

Midea VRF Series Specifications

General

Compressor Type	Inverter Scroll Compressor
Type	Variable Refrigerant Flow (VRF)
Refrigerant	R410A
Control	Centralized control, individual control
Indoor Unit Types	Wall mounted, cassette, ducted, floor standing
Energy Efficiency	High energy efficiency with DC inverter technology
Indoor Unit Noise Level	19 dB(A) to 45 dB(A)
