ECG Report Printer Format Settings
Item
Settings
Comments
Printer Format Settings
• 6 x 2 format
• 12-lead format (12x1)
• 12-lead plus single rhythm format
(3x4+1)
Default setting is 12-lead plus single rhythm format.
2-Page Format prints leads I, II, III, aVR, aVL, and aVF on the
first page, and V1-V6 (V3R-V7) on the second page. Select
the print scale of 25 mm/sec or 50 mm/sec when printing in
2-page format. Other formats will always print at the 25mm/
sec scale.
Rhythm Lead
Select any lead
I, II, III, aVR, aVL, aVF,
V1,V2,V3(V3R),V4(V7),V5,V6
Default setting is II.
Applies to 12-lead plus single rhythm format (3x4+1) as
described above.
The Rhythm Lead V3 (V3R) specifies Lead V3 if Standard 12-Lead (V1,V2,V3,V4,V5,V6) is selected when a new ECG test is started; it
specifies Lead V3R if Modified 12-Lead (V3R,V1,V2,V5,V6,V7) is selected. V4 (V7) has a similar definition.
The Rhythm Lead Group V1, V2, V3 (V3R, V1,V2) specifies V1, V2, V3 if Standard 12-Lead is selected; it specifies V3R, V1, V2 if
Modified 12-Lead is selected. The Rhythm Lead Group V4, V5, V6 (V5, V6, V7) has a similar definition.
Print After Analysis
On/Off
Default setting is Off (cleared).
When On, the resting ECG report is automatically printed
following analysis.
NOTE: For speed, set to Off and print manually.
Print Measurements
On/Off
Default setting is Off (cleared).
When this is On, the detailed measurement matrix report is
printed automatically with the ECG report.
Grid
On/Off
Black, Red, or Green
Default setting is On (checked).
When this is set to On, the grid is printed in the selected color
if a color printer is used.
