Midmark M9 - M11; M11 D Control PC Board

SECTION VI
PARTS LIST
M11 / M11D
Page 6-25
© Midmark Corporation 2002 SF-1827 Rev 9/10 Printed in U.S.A.
M11 / M11D Control PC Board
Always Specify Model & Serial Number
Item Part No. Description Qty.Item Part No. Description Qty.
•
Control PC Board - 115 V & 230V
(includes items 1 thru 4)
1 • • M11 EPROM .................................... Ref.
2 • 015-0346-08 • Printer Fuse (3 amp/250 V) ................. 1
3 • 015-0346-07 • Line Fuse (15 amp/250 V) {Used on
115 V Units Only} ................................ 2
4 • • 2 Position Jumper ............................ Ref
MA222001
1
2
3
4
ATTENTION
Control PC board is no longer available.
Please contact Midmark Technical Service for information about the PC board rebate program.
(Some restrictions may apply)
