Miele PFD 404 U - Technical Details

Technical details
109
Imperial Metric
Height with machine lid
Height without machine lid
32 7/8" adjustable+2 1/4"
32 5/16" adjustable+2 1/4"
835mm adjustable+ 60mm
820mm adjustable+60mm
Width 23 1/2"
598mm
Depth
Depth with door open
23 1/2"
47 1/4"
580mm
1,180mm
Weight (net) Approx.154lbs
Approx.70kg
Voltage, rated load, fuse rating See data plate See data plate
Power supply cord Approx. 5' 6"
Approx. 1.7m
Water connection water temperature:
Cold water/steam condenser (optional)
Hot water
Max. 68°F
Max. 149°F
Max. 20°C
Max. 65°C
Static water pressure Max. 145psi
1.000kPa overpressure
Minimum water connection flow pressure:
Cold water/steam condenser (optional)
Hot water
14.5psi
5.8psi
100kPa overpressure
40kPa overpressure
Recommended water connection flow pressure:
Cold water/hot water
Steam condenser (optional – connection via cold
water)
29psi
14.5psi
≥200kPa overpressure
≥200kPa overpressure
Water inlet hose Approx. 5' 7"
Approx. 1.7m
Drain hose Approx. 4' 9"
Approx. 1.5m
Delivery head Min. 1',
max.3' 3"
Min. 0.3m
max. 1.0m
Drainage length Max. 13' 1"
Max. 4.0m
Operating conditions:
Ambient temperature
Maximum relative humidity
Linear decrease to
Minimum relative humidity
40 - 104°F
80 % for temperatures up to 88°F
50% for temperatures up to 104°F
10%
5°C to 40°C
80% for temperatures up to 31°C
50% for temperatures up to 40°C
10%
Storage and transportation conditions:
Ambient temperature
Relative humidity
Air pressure
-4°F to 140°F
10% to 85%
7.25psi to 15.37psi
-20°C to 60°C
10% to 85%
500hPa to 1060hPa
Altitude above sea level (according to IEC/EN
60335)
Up to 6,561ft*
Up to 2,000 (m)*
Protection category (according to IEC 60529) IP21 IP21
Noise emission values
Sound power in LwA
Sound pressure in LpA
Undercounter installation with
wooden trim in front of toe-kick,
Short program
59dB(A)
47dB(A)
Undercounter installation with
wooden trim in front of toe-kick,
Short program
57dB(A)
45dB(A)
WiFi standard
802.11 b/g/n
WiFi frequency band
2,400-2,483.5MHz
Maximum WiFi transmission power
< 100mW
Certification marks Intertek approval
Manufacturer’s address Miele & Cie. KG, Carl-Miele-Strasse 29,
33332 Gütersloh, Germany
* If installation site is above 2,000m, the boiling point of the wash water will be lower. For this reason, the program parameters
may have to be adjusted.
