Technical Information
36
PW 6xx7
No. Program step Basic
setting
Setting options Notes
27 Program stop
signal 2
No No No stop signal at Program stop signal
output.
Yes During the program stop, the program
stop signal remains applied to the
Program stop signal output. When the
program is continued by pressing Start,
this signal is cancelled. This feature can
be used to provide a signal to operate,
e.g., a lamp or buzzer (connected via a
suitable kit).
28 Drainage path
1
No No No drainage takes place. If No is
selected, a spin speed > 70 rpm cannot
be set in the Spin program segment.
Spinning with water is prevented.
Drain Activation of the drain valve.
Reservoir Drained water is transferred to the water
recycling (WRG) tank.
Empty reservoir The control empties the water recycling
tank by opening the water recycling
intake (K6), drain valve (AVauf) and
water recycling (WRGauf) valves.
Cleaning Water is pumped into the water recycling
(WRG) tank and returned to the machine.
29 Drain level 1
0 mm Between 0 mm and the
value in mm of level 1
or level 2, whichever is
greater
If Wash time 4 for the current block has
been set to greater than 0 seconds
(should be at least as long as the drain
interval), Step 29 (“Drain level 1”) will
determine the water level (mm wc) for
drum spinning to take place during the
drain interval. Spin rhythm and speed are
programmed in “Wash time 4”. Drain level
1 can be set directly at the machine, but
only between the maximum level in the
current block and 0 mm wc. With the
Miele Profitronic M programming and
archiving software, however, Drain level 1
can be set between 350 and 0 mm wc.
For further details, see Section 100-4.3.
30 Wash time 4
No No No Wash time 4 carried out (wash time
for water drainage before spin).
User-defined The programmer sets the drum agitation
for washing for a set duration with set
rhythm and speed. Time selectable
between 0 min 0 s and 99 min 59 s in 1-s
steps. Rhythm options “No”, “Normal”,
“Gentle+”, “Gentle” and “User- defined”.
With “User-defined”, the on time must be
between “2 s" to “99 s" and the off time
between “2 s” and “99 s” with the sum >
15 s. Speed options “No”, “Normal”,
“Drench” and “User-defined”. “User-
defined” selectable between 20 rpm and
70 rpm in 1-rpm steps.
31 Drainage path
2
Drain (route
for water
extracted in
spin cycle)
No No drainage takes place. If No is
selected, a spin speed > 70 rpm cannot
be set in the Spin program segment.
Spinning with water is prevented.
Drain Activation of the drain valve.
Reservoir Drained water is transferred to the water
recycling (WRG) tank.
