Miele PWM 307 User Manual

3. Selecting a programme and settings
27
Switching on the washing ma-
chine
 Press the control.
Selecting a programme
 Turn the programme selector to the
required programme.
The selected programme will be shown
in the display. The display will then
change to the standard menu for that
programme.
Selecting a temperature
You can alter the preset temperature of
certain programmes.
 Touch the Temperaturesensor con-
trol.
 Select the desired temperature.
The selected temperature is marked
with a frame.
Selecting the spin speed
You can alter the preset spin speed.
 Touch the Spin speedsensor.
The following will appear in the display:

Spin speed
800
1000
400
0
1200
1600
 Select the spin speed you want.
The selected spin speed is marked with
a frame.

Miele PWM 307 Specifications

General

Current	10 A
Connected load	2400 W
AC input voltage	220 - 240 V
AC input frequency	50 Hz
Energy efficiency scale	A to G
Power consumption (off)	0.4 W
Water consumption per cycle	37 L
Energy consumption washing per cycle	- kWh
Package depth	768 mm
Package width	660 mm
Package height	944 mm
Package weight	102000 g
Door color	Silver
Door hinge	Right
Water fill	Cold
Cord length	2 m
Drum volume	64 L
Control type	Rotary, Touch
Loading type	Front-load
Certification	CE, VDE EMC, VDE, WEEE
Product color	White
Built-in display	Yes
Inlet hose length	1.55 m
Custom panel-ready	-
Door opening angle	167 °
Illumination color	Yellow
Outlet hose length	1.5 m
Appliance placement	Freestanding
Dispenser tray type	3-way
Drum capacity	7 kg
Cycle time (max)	199 min
Delay start (max)	24 h
Residual moisture	48 %
Maximum spin speed	1400 RPM
Noise level (spin)	72 dB
Noise level (wash)	50 dB
Number of washing programs	12
Cycle time (quick washing program)	15 min

Weight and Dimensions

Depth	714 mm
Width	596 mm
Height	850 mm
Weight	98000 g
Door diameter	300 mm
