Miele PWM 307 User Manual

Before using for the first time
20
 Damage resulting from incorrect
installation and connection.
Installing and connecting the wash-
ing machine incorrectly will cause
serious property damage.
See “Installation”.
Emptying the drum
A swivel elbow for the drain hose and/
or assembly material may be stored in
the drum.
 Pull open the door.
 Remove the swivel elbow and as-
sembly material.
 Shut the door with a gentle swing.
Switching on the washing ma-
chine
 Press the control.
The welcome screen will light up.
When commissioning the washing
machine for the first time, you will
have to define settings for daily use
of the appliance. Some settings can
only be configured during the initial
commissioning process. After that,
they must be changed by Miele Ser-
vice.
Complete the initial commissioning
process.
These settings are also described under
“Supervisor level”.
Setting the language
You will be asked to select the language
you require for the display. You can
change the language at any time (see
“Language” under “Supervisor level”).

Language


deutsch
čeština
english
(AU)
dansk
 Touch the orsensor until the
language you want appears in the
display.
 Touch the sensor for the language
you want.
The selected language is marked with a
frame and the display will change to
next setting.

Miele PWM 307 Specifications

General

Current	10 A
Connected load	2400 W
AC input voltage	220 - 240 V
AC input frequency	50 Hz
Energy efficiency scale	A to G
Power consumption (off)	0.4 W
Water consumption per cycle	37 L
Energy consumption washing per cycle	- kWh
Package depth	768 mm
Package width	660 mm
Package height	944 mm
Package weight	102000 g
Door color	Silver
Door hinge	Right
Water fill	Cold
Cord length	2 m
Drum volume	64 L
Control type	Rotary, Touch
Loading type	Front-load
Certification	CE, VDE EMC, VDE, WEEE
Product color	White
Built-in display	Yes
Inlet hose length	1.55 m
Custom panel-ready	-
Door opening angle	167 °
Illumination color	Yellow
Outlet hose length	1.5 m
Appliance placement	Freestanding
Dispenser tray type	3-way
Drum capacity	7 kg
Cycle time (max)	199 min
Delay start (max)	24 h
Residual moisture	48 %
Maximum spin speed	1400 RPM
Noise level (spin)	72 dB
Noise level (wash)	50 dB
Number of washing programs	12
Cycle time (quick washing program)	15 min

Weight and Dimensions

Depth	714 mm
Width	596 mm
Height	850 mm
Weight	98000 g
Door diameter	300 mm
