Installation
*INSTALLATION*
61
Securing the washing machine with
the holding bracket
 Push the washing machine back on
to the installed holding bracket.
 Insert the appliance feet (the part
between the foot and the locknut)
into the openings in the holding
bracket.
 Push the holding bracket to the right
as far as it will go.
 Tighten the hexagon screws using a
spanner.
The washing machine is secured in the
holding bracket.
External control equipment
The XCI box accessory is needed to
connect external control equipment,
such as payment systems.
Payment system
This washing machine can be fitted with
a payment system (optional accessory).
The necessary reprogramming must al-
ways be carried out by Miele Service or
a Miele Service Dealer.
Coins/tokens must be removed from
the coin box regularly. Otherwise, the
payment system will become blocked.

Miele PWM 307 Specifications

General

Current	10 A
Connected load	2400 W
AC input voltage	220 - 240 V
AC input frequency	50 Hz
Energy efficiency scale	A to G
Power consumption (off)	0.4 W
Water consumption per cycle	37 L
Energy consumption washing per cycle	- kWh
Package depth	768 mm
Package width	660 mm
Package height	944 mm
Package weight	102000 g
Door color	Silver
Door hinge	Right
Water fill	Cold
Cord length	2 m
Drum volume	64 L
Control type	Rotary, Touch
Loading type	Front-load
Certification	CE, VDE EMC, VDE, WEEE
Product color	White
Built-in display	Yes
Inlet hose length	1.55 m
Custom panel-ready	-
Door opening angle	167 °
Illumination color	Yellow
Outlet hose length	1.5 m
Appliance placement	Freestanding
Dispenser tray type	3-way
Drum capacity	7 kg
Cycle time (max)	199 min
Delay start (max)	24 h
Residual moisture	48 %
Maximum spin speed	1400 RPM
Noise level (spin)	72 dB
Noise level (wash)	50 dB
Number of washing programs	12
Cycle time (quick washing program)	15 min

Weight and Dimensions

Depth	714 mm
Width	596 mm
Height	850 mm
Weight	98000 g
Door diameter	300 mm
