Miele PWM 307 User Manual

Installation
*INSTALLATION*
60
 Place the holding bracket on the front
appliance feet.
 Mark the position of the front edge of
the holding bracket with a pencil.
 Remove the holding bracket from the
feet.
 Carefully move the washing machine
until you have enough space to install
the holding bracket.
Installing the holding bracket
 Place the holding bracket on the
marking on the plinth.
 In the middle of the two outer slotted
holes, mark a point for each drill hole.
 Drill 2holes (8mm) with a depth of
approx. 55mm.
 Insert the plugs in the holes.
 Install the holding bracket with the
hexagon screws and the washers.
Do not tighten the screws yet – this
will allow the holding bracket to be
moved sideways.

Miele PWM 307 Specifications

General

Current	10 A
Connected load	2400 W
AC input voltage	220 - 240 V
AC input frequency	50 Hz
Energy efficiency scale	A to G
Power consumption (off)	0.4 W
Water consumption per cycle	37 L
Energy consumption washing per cycle	- kWh
Package depth	768 mm
Package width	660 mm
Package height	944 mm
Package weight	102000 g
Door color	Silver
Door hinge	Right
Water fill	Cold
Cord length	2 m
Drum volume	64 L
Control type	Rotary, Touch
Loading type	Front-load
Certification	CE, VDE EMC, VDE, WEEE
Product color	White
Built-in display	Yes
Inlet hose length	1.55 m
Custom panel-ready	-
Door opening angle	167 °
Illumination color	Yellow
Outlet hose length	1.5 m
Appliance placement	Freestanding
Dispenser tray type	3-way
Drum capacity	7 kg
Cycle time (max)	199 min
Delay start (max)	24 h
Residual moisture	48 %
Maximum spin speed	1400 RPM
Noise level (spin)	72 dB
Noise level (wash)	50 dB
Number of washing programs	12
Cycle time (quick washing program)	15 min

Weight and Dimensions

Depth	714 mm
Width	596 mm
Height	850 mm
Weight	98000 g
Door diameter	300 mm
