Miele PWM 307 User Manual

Supervisor level
70
Language
The display can be set to appear in
one of several different languages. To
select the permanent operator lan-
guage you want, go to the Languages
sub-menu.
When a programme is running, you can
change the user language using the
sensor.
Brightness
The brightness of the display can be
set in intervals of ten from 10% to
100%.
Factory default: 70%
Clock display
After selecting the clock format, you
can set the time of day.
Clock format
- 24h clock (factory default)
- 12h clock
- Clock off
Set
- The time of day can be set.
Finish tone volume
The volume can be changed for the
buzzer that sounds at the end of the
programme.
It can be set to one of 7 different levels
or switched off altogether.
Factory default: Off
Keypad tone volume
The volume of the tone that sounds
when a sensor is touched can also be
changed.
It can be set to one of 7 different levels
or switched off altogether.
Factory default setting: normal
Welcome tone volume
The volume of the welcome tone that
sounds when the washing machine is
switched on can be changed.
It can be set to one of 7 different levels
or switched off altogether.
Factory default setting: normal
Fault alarm
The tone that sounds in the event of a
fault can be switched on or off.
Factory default: Off
Memory
The washing machine will save the
settings (temperature, spin speed and
some of the options) which have been
selected for a programme after the
programme has started.
When the programme is chosen again,
the saved settings will appear in the
display.
Factory default: Off

Miele PWM 307 Specifications

General

Current	10 A
Connected load	2400 W
AC input voltage	220 - 240 V
AC input frequency	50 Hz
Energy efficiency scale	A to G
Power consumption (off)	0.4 W
Water consumption per cycle	37 L
Energy consumption washing per cycle	- kWh
Package depth	768 mm
Package width	660 mm
Package height	944 mm
Package weight	102000 g
Door color	Silver
Door hinge	Right
Water fill	Cold
Cord length	2 m
Drum volume	64 L
Control type	Rotary, Touch
Loading type	Front-load
Certification	CE, VDE EMC, VDE, WEEE
Product color	White
Built-in display	Yes
Inlet hose length	1.55 m
Custom panel-ready	-
Door opening angle	167 °
Illumination color	Yellow
Outlet hose length	1.5 m
Appliance placement	Freestanding
Dispenser tray type	3-way
Drum capacity	7 kg
Cycle time (max)	199 min
Delay start (max)	24 h
Residual moisture	48 %
Maximum spin speed	1400 RPM
Noise level (spin)	72 dB
Noise level (wash)	50 dB
Number of washing programs	12
Cycle time (quick washing program)	15 min

Weight and Dimensions

Depth	714 mm
Width	596 mm
Height	850 mm
Weight	98000 g
Door diameter	300 mm
