Miele PWM 307 User Manual

Technical data
66
Height 850mm
Width 596mm
Width (for appliances with a stainless steel
lid)
605mm
Depth 714mm
Depth with door open 1132mm
Weight Approx. 100kg
Maximum floor load in operation 3000newtons
Capacity 7.0kg dry laundry
Supply voltage See data plate on back of appli-
ance
Rated load See data plate on back of appli-
ance
Fuse rating See data plate on back of appli-
ance
A-rated sound emissions L
pA
in accordance
with ENISO11204/11203
<70dB re 20µPa
Minimum water flow pressure 100kPa (1bar)
Maximum water flow pressure 1000kPa (10bar)
Water inlet hose length 1.55m
Connection cable length 1.80m
Maximum delivery head (drain pump) 1.00m
LEDs Class1
Product safety standard EN50571, EN60335
Test certifications awarded See data plate
Power rating in off mode 0.50W
Networked standby 0.90W
Frequency band of the WiFi module 2.4000GHz–2.4835GHz
Maximum transmission power of the WiFi
module
<100mW

Miele PWM 307 Specifications

General

Current	10 A
Connected load	2400 W
AC input voltage	220 - 240 V
AC input frequency	50 Hz
Energy efficiency scale	A to G
Power consumption (off)	0.4 W
Water consumption per cycle	37 L
Energy consumption washing per cycle	- kWh
Package depth	768 mm
Package width	660 mm
Package height	944 mm
Package weight	102000 g
Door color	Silver
Door hinge	Right
Water fill	Cold
Cord length	2 m
Drum volume	64 L
Control type	Rotary, Touch
Loading type	Front-load
Certification	CE, VDE EMC, VDE, WEEE
Product color	White
Built-in display	Yes
Inlet hose length	1.55 m
Custom panel-ready	-
Door opening angle	167 °
Illumination color	Yellow
Outlet hose length	1.5 m
Appliance placement	Freestanding
Dispenser tray type	3-way
Drum capacity	7 kg
Cycle time (max)	199 min
Delay start (max)	24 h
Residual moisture	48 %
Maximum spin speed	1400 RPM
Noise level (spin)	72 dB
Noise level (wash)	50 dB
Number of washing programs	12
Cycle time (quick washing program)	15 min

Weight and Dimensions

Depth	714 mm
Width	596 mm
Height	850 mm
Weight	98000 g
Door diameter	300 mm
