MM571W / MM572W Installation Instructions 11
PUSH-TO-OPEN OPERATOR MOUNTING
Step 8
Step 9
● Secure the gate post bracket subassembly
with the supplied hardware as shown.
● Using a drill and 7/16” drill bit, drill the
necessary holes to mount the gate post
and gate brackets.
Note: Some installations may require
additional reinforcement be installed on
the gate.
M
L
T
