12 MM571W / MM572W Installation Instructions
T
V
L
L
P
N
N
S
S
● Secure the gate bracket with the
supplied hardware as shown.
● Once the gate post and gate
brackets are installed, reattached
the operator arm.
● Ensure the operator arm is
level, adjusting the post bracket
location if necessary.
● Once level, ensure all hardware
is tight.
● Remove excess bolt length with a
hacksaw.
PUSH-TO-OPEN OPERATOR MOUNTING
Step 10
Step 11
