OM-261050 Page 81
Description
Part
No.
Dia.
Mkgs.
Item
No.
Figure 15-2. Controls/Remote Assemblies
Quantity
1 274336 Circuit Card Assy, Open Center Control System W/Enc (Includes) 1... .......... .. ......
1 274343 Circuit Card Assy, Closed Center Cntrl System W/Enc(Includes) 1... .......... .. ........
2 260718 Nameplate, Enpak Service Panel 1... .......... ... .................................
3F1−4 239347 Fuse, 20 Amp Ato Type 4... ... . ... .........................................
4 239346 Relay, Encl 12vdc Spdt 30a/20a 5pin Flange Mtg 3... .......... ... ...................
5 261891 Cover 1... .......... ... .........................................................
264402 Rivet, Plastic .312 Hole X .139-.334 Grip Push 2................ ... .....................
6 287065 Label, Warning Unexpected Starting 1... .......... ... ..............................
7 217395 Bumper,Door .500 Od X .250 High Nprn 70 Duro 1... .......... ... ...................
261028 Circuit Card Assy, Remote Panel W/Enclosure (Includes) 1................ .. ..............
8 251878 Enclosure, Rear Remote Panel 1... .......... ... ..................................
9 261076 Circuit Card Assy, Remote Panel W/Program 1... .......... ... ......................
10 251877 Enclosure, Front Remote Panel 1... .......... ... ..................................
11 248998 Nameplate, EnPak Remote Panel 1... .......... ... ................................
12 231297 Actuator Push Button Assy 5... .......... ... ......................................
13 *244283 Cable, Interconnecting Power 30 Ft 6/C 2... .......... .. ............................
260911 Bracket, W/Components/Harness (Includes) 1................. .. .........................
14 287064 Label, Warning Electric Shock 1... .......... ... ...................................
15 237883 Bracket, Mtg Components 1... .......... ... .......................................
16 057357 Bushing, Snap−in Nyl .937 Id X 1.125 Mtg Hole 4... .......... ... ...................
17 173734 Link, Jumper 2... .......... ... ...................................................
18 1T 172661 Block, Stud Connection 6 Position 1... .... .. ... ................................
19 CB2 093996 Supplementary Pro, Man Reset 1p 20a 250vac Frict 1... ... .. ... ................
20 CB1 241885 Supplementary Protector, Man Reset 2p 25a 240vac 1... ... .. ... ...............
21 C1, C2 273009 Capacitor, Polyp Met Film 60. Uf 440 Vac (Alum) 2... .. ... ...................
22 239020 Bracket, Cap Clamp 1... .......... ... ............................................
23 239021 Cover, Aux Power Enclosure 1... .......... ... ....................................
24 265529 Label, Warning Electric Shock W/Terminal Strip 1... .......... ... ....................
25 190058 Nut, 250−20 U−nut Multi−thread 1... .......... ... .................................
26 CB4 190374 Circuit Breaker, Auto Reset 12vdc 40 Amp 1... ... .. ... .........................
27 CR1 *197325 Relay, Encl 12vdc Spst 70a 4pin Flange Mtg 1... ... .. ... .......................
CT1 237905 Xfmr, Current Sensing 1......... .. ... ...........................................
28 204737 Cable Tie Mount, Winged Push 4... .......... ... ..................................
29 034055 Screw, 250−20x2.50 Hex Hd−pln Stl Pld 1... .......... ... ...........................
*Recommended Spare Parts.
To maintain the factory original performance of your equipment, use only Manufacturer’s Suggested
Replacement Parts. Model and serial number required when ordering parts from your local distributor.
MILLER Recommended GFCI Receptacles
Hubbell /Bryant GF20 series only
Typical part numbers for 20 ampere receptacles:
Brown GF20LA........ .............
Almond GF20ALLA........ ............
Black GF20BKLA........ .............
Gray GF20GYLA......... .............
Ivory GF20ILA......... .............
White GF20WLA........ .............
MILLER Recommended Circuit Breaker For 120 VAC Generator Power
CB2 093996 Supplementary Pro, Man Reset 1p 20a 250vac Frict 1......... .. ... ................
