. A complete Parts List is available at www.MillerWelds.com
OM-272989 Page 29
5-15. Removing MIG Gun To Replace With A Spool Gun
Open Pressure Assembly.
. Hold wire tightly to keep it
from unraveling.
Rewind Wire Onto Spool, Fasten
End Of Wire To Spool.
Cut Off End Of Wire.
Loosen Knob, Disconnect Gun Trigger
Plug, And Remove Gun From Unit.
(See Section 5-11 For Gun Installation.)
275178A / Ref. 802982A / Ref. 275174A / Ref. 267807A
Knob
Turn Off Power.
To Next Page
