INTERCONNECTION
Before interconnecting system components to the XPL+ terminals, verify all components have been installed
in accordance with the associated product instruction manuals.
Connect all associated equipment cable shields to the XPL+ shield connections. To avoid differential ground
potentials, do not connect cable shields to ground (earth) elsewhere. Insulate (tape) cable shields at all
shield junctions to prevent ground loops.
board B
terminal block
EPROM
SW1
voltage
selection
display
scope connections
board A
optional
TIB-9
optional
SmartLinx
module
Hazardous voltage present on transducer terminals during operation.
All field wiring must have insulation suitable for at least 250 V.
