P733 (G) SCROLL ACCESS
Use this feature to select the programming mode parameter scroll access option desired.
Select: "off" to scroll access all operator accessible parameters ( P000 to P999 ).
"smart" to scroll access Quick Start, previously altered, and tagged parameters.
"tagged" to scroll access operator tagged parameters only.
If SmartLinx module is installed, the applicable protocol specific parameters
(P750 - P789) are preset as tagged.
( Any accessed parameter may be
tagged
or
untagged
by pressing ).
is displayed when a previously tagged or altered parameter is accessed.
values: 0 = off
1 = smart (preset)
2 = tagged
P734 (G) SCANNING INDICATORS
Use this feature to have the Scan Point indicators display the Point Numbers currently "on
priority" ( see SMART SCAN, P720 ). As preset, the Point Number being scanned is displayed.
values: 1 = Point Number being scanned
2 = Point Numbers on priority
P740 PERIPHERAL COMMUNICATIONS
Use this feature to select the ASCII message format used in Milltronics
proprietary communications loop.
Select: "off" if peripherals are not used. ( increases the XPL+ processing speed )
"normal" to have messages transmitted in a continuous string of characters.
( requires less XPL+ processing time than formatted messages )
"formatted" to have commas inserted between the message fields.
(for easier message recognition e.g. when viewed on a monitor )
Refer to BIC-II Support if a BIC-II is used.
values: 0 = off
1 = normal ( preset )
2 = formatted messages
%
TECHNICAL REFERENCE
PL-532 66
