P-25 relay 2 pump log *
P-26 relay 3 pump log *
P-27 relay 4 pump log *
P-28 relay 5 pump log *
* these are multi-level parameters related to the respective relays when assigned
to a pump control function. Access to the levels is made by pressing .
e.g. P - 24 ‘ running hours ’ log
C - 24 ‘ starts ’ log
A - 24 pumping ratio
P - 24 ‘ running hours ’ log
The running hours are displayed by pressing
while viewing P - 24 through P - 28.
P - 24 ‘ running hours ’ log
1 2 3 4 1,234 hours of running
time ( F = 0.000 )
The number of starts is displayed by pressing
while viewing C - 24 through C - 28.
C - 24 ‘ starts ’ log
321 321 pump starts ( F = 0 )
The ratio settings are entered by pressing while viewing A-24
through A-28.
e.g. A-24 pump ratio
20 20 % (F=20)
5 5 %
5.000
*
*
ALT
DISP
*
5
ALT
DISP
Enter
ALT
DISP
ALT
DISP
*
ALT
DISP
ALT
DISP
PL-399 7 – 4
