5-3-2. HEAD ADJUST
[Function]
Plots a pattern for mechanical adjustment of position shift of each head.
[Operation]
1) Select the ADJUSTMENT.
Press the
ENTER
key.
2) Press the
FUNCTION
key to select the “HEAD
ADJUST”
Press the
ENTER
key.
3) Select the adjustment item using the
or
key.
If “SLANT adjust” has been selected )
1) Select the print-type (720, 4pass / 360, 2pass)
using the
or key.
Press the
or key to change the position
(only X position) to plot.
2) Press the
ENTER
key to start drawing.
FUNCTION
# ADJUST < ENT >
# ADJUST
HEAD ADJUST < ent >
#ADJUST
SLANT adjust < ent >
#HEAD ADJUST
UNIT ADJUST < ent >
#ADJUST
TYPE : 720 4pass
#ADJUST
PRINT START : ent
If “UNIT ADJUST” has been selected )
Press the
ENTER
key to start drawing.
#ADJUST
PRINT START : ent
