– 5.39 –
5-4-4. X SERVO
[Function]
Continuous forward/reverse travel is executed in terms of the X-direction for the purpose of
durability test.
This test can be executed without placing a media on the plotter.
• Execute the test with speed, acceleration and traveling amount set to the initial val-
ues. If they are excessively increased, the plotter can break.
• Note that executing this function with ink filled may cause ink leakage from the head.
[Operation]
1) Select the “TEST”.
Press the
ENTER
key.
2) Select the “X SERVO” pressing the
FUNCTION
key.
Press the
ENTER
key.
3) Press the
ENTER
key twice without
changing the set value.
Now, the screen changes over to permit the setting
of a traveling amount in the X-direction.
4) Press the
ENTER
key without changing the
set value.
The aging in the X-direction starts.
• Temperature adjustment can be
performed by pressing the
HEATER
key during aging.
5) Press the key to interrupt the
operation.
FUNCTION
# TEST < ENT >
# TEST
X SERVO < ent >
# X SERVO
X : S = ∗ ∗ ∗ A = ∗ .∗ ∗
# X SERVO
X = ∗ ∗ ∗
# TEST
X SERVO < ent >
To Next Page
