5-4. #TEST items
5-4-1. CHECK PATTERN
[Function]
Plots the following patterns with the selected plotting mode to check the machine status.
a. Density pattern..................... Patterns are drawn for the density of 100%, 50%, 25%, and
6.25%. (Colors can be selected.)
b. Nozzle check ....................... A nozzle checking pattern is drawn (Colors can be selected.)
c. Color chart ........................... K, C, M and Y color patterns are drawn (four colors model).
K, C, M, Y, Lm and Lc color patterns are drawn (six colors
model).
d. Feed ..................................... Checks the amount of feed with 1-head 1-nozzle
configuration. (Colors can be selected.)
[Operation]
1) Select the TEST.
Press the
ENTER
key.
2) Select the “CHECK PATTERN” pressing the
FUNCTION
key.
Press the
ENTER
key.
3) Select a pattern using the
and keys.
Pattern : 100%
50%
25%
6.25%
NOZZLE
COLOR
FEED
• If two or more colors are selected, a density pattern is drawn while mixing the
selected colors. Note that, however, nozzle checking patterns are respectively
plotted for the selected colors.
• When necessary items have been specified for each pattern and the device is
ready for plotting, you can set the plot position, the head to be used, and the
number of scans before pressing the
ENTER
key.
# CHK PATTERN
PATTERN : 100%
FUNCTION
# TEST < ENT >
# TEST
CHK PATTERN < ent >
To Next Page
