– 5.65 –
5-5. #PARAMATER items
5-5-1. SYSTEM PARAMETER
[Function]
System parameter values are changed.
[System parameters list]
No. Indication Set value Description Remarks
0COMP.X 0 Mechanical correction X
(in increments of 0.1 mm 500 mm – actual measured value)
1COMP.Y 44 Mechanical correction Y
(in increments of 0.1 mm 500 mm – actual measured value)
2R GRIP 0 Adjustment of dead space on the right-hand side of the paper
(in increments of 0.1 mm 25 mm - actual measured value)
3L GRIP 0 Adjustment of dead space on the left-hand side of the paper
(in increments of 0.1 mm 5 mm - actual measured value)
4 CAPpodY 20 Adjustment of capping Y position (in increments of 0.1 mm)
5 PULLpos 25 Idle suction position (in increments of 0.1 mm)
6 FLSposY 0 Adjustment of flashing Y position (in increments of 0.1 mm)
7 WIPposY 35 Adjustment of wiping Y position (in increments of 0.1 mm)
8 DE0D0sw 0 Exhaust fan operation switch 0:Operate /1:Not operate
*Charging MS2 ink is 1
9 CUTposi 0 Adjustment X of the medium cutting position Adjustment value in the
(in increments of 0.1 mm) X-direction when cutting
10 EDGE LV 50 Medium edge detection level (Unit: %) Edge detection level
when the media width is
detected
11 H12dist 252 Distance between head 1/nozzle row A and head 2/nozzle row A
12 H13dist 640 Distance between head 1/nozzle row A and head 2/nozzle row A
13 H14dist 792 Distance between head 1/nozzle row A and head 4/nozzle row A
14 RESERVE 0 RESERVE
18 HIGHTsw 3 Switch that load the head height sensor
19 Xmtr.sw 0 Switch to change the Xmotor lotate direction
20 FEEDadj 25 X feed pulse correction (in increments of 1 dot)
21 V1BiADJ 0
Correction base value for V1 waveform Y direction shuttle movement
(in increments of 1 dot)
22 V2BiADJ 0
Correction base value for V2 waveform Y direction shuttle movement
(in increments of 1 dot)
23 N1BiADJ 0
Correction base value for N1 waveform Y direction shuttle movement
(in increments of 1 dot)
24 N2BiADJ 0
Correction base value for N2 waveform Y direction shuttle movement
(in increments of 1 dot)
25 V1HBiAJ 6 Correction value for V1 waveform doubled shuttle movement
(in increments of 1 dot)
26 V2HBiAJ 4 Correction base value for V2 waveform doubled shuttle movement
(in increments of 1 dot)
27 RESERVE 0 RESERVE
28 RESERVE 0 RESERVE
29 RESERVE 0 RESERVE
30 WormORG 0 Worm origin
31 WSsleep 0 Switch to sift the sleep function when using MS2ink
0:Not operate/1:Operate
38 OPT 75SP 0 Option switch for 75SP II
39 TKupVsw 0 Switch to change the electric pressure for light weight take up reel
0:4.5V/13.6V 1:15.4V/24.4V
40 TAKunit 0 Switch to change the electric pressure for heavy weight take up reel 0:Disabled / 1:Enabled
Adjustment of range and
accuracy
If the system parameter
value is incrased:
Length of peint incrased
Adjustment value for
edge adjustment
If the system parameter
value is increased: dead
space os reduced.
