– 5.31 –
a. Plotting a density pattern
1) Select the density pattern using the or
key and press the
ENTER
key.
Pattern : 100%, 50%, 25%, 6.25%
2) Select the resolution using the
or key
and press the
ENTER
key.
Resolution : 360 x 360- N1, 360 x 360- V1,
360 x 540- N1, 360 x 540- V1,
720 x 720- N2, 720 x 720- V2,
1440 x 1440 -V2, 180 x 180- N1,
180 x 180- V1, 360 x 720- V1,
360 x 720- N1, 720 x 1440- V2,
720 x 1440- N2
3) Select the drawing way using the
or
key and press the
ENTER
key.
Drawing way : BI-D 1,2,3,4,6,8,12,16,32 pass
UNI-D 1,2,3,4,6,8,12,16,32 pass
• Some items cannot be selected and
other combinations may apply
depending on the ink set (4 colors,
6 colors) or the resolution.
4) Select the plotting length in the XandY-
direction using the
or key and press
the
ENTER
key.
Length setting: 10 mm to the sheet length (in
increments of 10 mm)
5) Select the color used for plotting.
Shift the cursor using the
or key to select
the color to be used.
Press the
or key to select whether the
color is drawned or not.
Press the
ENTER
key to finalize the
number.
# CHK PATTERN
PATTERN : 100%
# CHK PATTERN
DPI : 360X360-N1
# CHK PATTERN
PLOT : UNI–D 2 pass
# CHK PATTERN
X = 10 Y = ∗ ∗ ∗ ∗ ∗
# CHK PATTERN
COLOR : KMCYmc
