MIMAKI JV3-130SL User Manual

– 5.50 –
7) Press the
key.
The state of the front cover sensor is shown on
the LCD.
ON: The front cover has been opened.
OFF: The front cover has not been closed.
Step 8) is only for 75SPII and 130SPII. For 160SP, go to step 9)
8) Press the key.
Head height sensor condition appear.
Thin: Head sensor low
High:Head sensor up
9) Press the
key.
Current status of ink pack sensor is displayed.
The color codes of the cartridges that have run
out of ink are appear.
10) Press the
key.
Current status of ink end sensor is displayed.
The color codes of the cartridges that have run
out of ink are appear.
11) Press the
key.
Current status of power of heater is displayed.
ON: Power on.
OFF: Power off.
Step 8) is only for 75SPII and 130SPII. For 160SP, go to step 9)
12) Press the key.
CG and I/F input condition apeear
13) Press the
key.
CG and I/F input condition apeear
Press the
key in repetition to return the layers
of screens one by one.
14) Press the
key to exit from the
function.
Press the
ENTER
key to start the initial
operation.
# TEST
HEATER POW : OFF
# TEST
SENSOR TEST < ent >
# SENSOR TEST
FRONT COVER
# TEST
INK END – – – – – –
# TEST
INK PACK – – – – – –
# SENSOR TEST
HEAD HIGHT :Thin
# SENSOR TEST
CGIF IN :ON/OFF
# SENSOR TEST
CGIF OUT :ON/OFF
