– 3.4 –
ERROR20 I/F BOARD
ERROR21 I/F NONE
ERROR23 HOST I/F
ERROR24 I/F INITIAL
ERROR30 OPERATION
ERROR34 DATA REMAIN
ERROR37
HAED_POSITION
* 75SPII, 130SPII only
ERROR40 MOTOR X
ERROR41 MOTOR Y
ERROR42 X CURRENT
ERROR43 Y CURRENT
•A error occurred in
communication between the
main PCB and the interface
board.
• The I/F board could not be
recognized.
•A time limit exceeded error
occurred in communication
between the host computer
and the interface board.
• The I/F board is in abnormal
conditions.
• Improper operation has been
performed.
• Operating condition is tried to
be changed when data that has
not yet been plotted remains.
• Adjustment of head angle and
head unit were enforced while
the head is set high.
• The X-axis motor has been
overloaded.
• The Y-axis motor has been
overloaded.
• The brush of motor is in
abnormal conditions.
• Overcurrent error has arisen
on the X-axis motor
• Overcurrent error has arisen
on the Y-axis motor
1) Replace the I/F PCB with a
new one.
2) Replace the main PCB with a
new one.
3) Replace the I/F connection
board with a new one.
4) Supply power to the 1394 PCI
board in the PC through the
power cable.
1) Is the I/F board mounted
correctly ?
1) Is the cable loose?
2) Has an error occurred on the
host computer?
3) Is the application being used
running normally?
1) Replace the I/F PCBwith a
new one.
2) Replace the main PCB with a
new one.
3) Replace the main PCB with a
new one.
1) Indicate the improper
operation.
2) Replace a key board.
3) Replace a main PCB.
1) This tells that any of the
operating conditions cannot be
changed if data that have not
been plotted remains.
1) Put the head position down.
1) Replace X axis motor.
2) Replace a main PCB.
1) Clean the main guide axis.
2) Execute an error maintenance
flow for Y motor.
3) Replace a main PCB.
1) Replace X axis motor.
2) Replace a main PCB.
1) Execute an error maintenance
flow for Y motor.
2) Replace a main PCB.
Message Description
Corrective measures and
recovering procedures
To Next Page
