– 4.10 –
5) To prevent spill the cleaning liquid in
damper into the head PCB, pull the
syringe piston a little back to dent the
damper film.
6) Take the damper off carefully.
(Do not pull off the damper. Remaining
liquid in damper may spatter over the
head PCB. Take it off carefully.)
• Do not drop the cleaning liquid.
7) Take off the leaked liquid in black resin
by using bem cotton or kim towel.
• Do not work with the cleaning
liquid remaining at A.
(If tilting the head with the liquid
remaining or working with the
liquid on your hands, the liquid
may run through B and reach to
the PCB.
Be sure to wipe the cleaning liquid
up by bem cotton or kim towel
before working.)
Damper film
To Next Page
