Mindray BA-88A Operation Manual

4-2
5
Buttons Function
Query Click Query to pop up the following page.
Select data range or patient name or/and Sample ID to search for
results that meet the requirement.
Add Add new patient information.
Edit Select one sample to a sample result to enter the Edit page or enter
the page directly.
The editing function will be elaborated separately in the following.
Delete Delete all the result of the selected test, when it is displayed by test.
Delete all the result of the selected sample, when it is displayed by
sample.
Upload Send all the result of the selected sample to LIS.
Print Print the report of the selected sample.
Return Click this button to return to the main screen.

Mindray BA-88A Specifications

General

Light source	Halogen lamp
Display	7 inch touch screen
Printer	Thermal printer
Interface	RS232
Wavelengths	340, 405, 546, 578, 630nm
Carry-over	< 1%
Power Supply	AC 100~240V, 50/60Hz
Operating Temperature	15-30°C
