Mindray BeneView T6 Service Manual

5-19
2. Unscrew the four M3×6 screws as shown in the figure above and take out the main
board that includes the mother board and the CPU board.
3. Unscrew the four M2.5×6 screws and separate the mother board from the CPU board.
Be sure not to damage the socket that connects the two boards. There is a battery on the
CPU board.
Battery
