5-42
5.6 Disassembling Modules
WARNING
z For a reassembled module, a patient leakage current test must be performed
before it is used again for patient monitoring.
z Make sure the monitor is off before disassembling the modules.
The monitor supports three types of modules, single-slot modules, 2-slot modules and 3-slot
modules. The following part describes two typical disassembling procedures.
5.6.1 Disassembling the ICG Module
1. Unscrew the two contact screws andф3 spring washer on the back with a sharp nose
pliers.
Contact Screw
To Next Page
