5-41
7. Use the sleeve to unscrew the hexagon nut and countersunk external toothed lock
washer assembly which can be further separated into the washer, springlet and contact
screw.
Hexagon nut and countersunk
external toothed lock washer
assembly
Washer
Springlet
Contact screw
