6-6

SN P/N Description Qty

7 6800-20-50220 PC cusion 1 1

8 6800-20-50221 PC cusion 2 1

9 6800-20-50228 Dust-proof pad 7 2

10 6800-20-50227 Dust-proof pad 6 2

11 6800-20-50207 Screen support 4(for 17” anit-glare screen) 1

12 M04-004012--- Crosshead screw M3×6 22

13 6800-20-50232 Backlight board insulating sheet 1

14 M04-002505--- Crosshead screw M3×6 2

15 6800-20-50671 Backlight board shielded cover 1

16 6800-20-50692 Backlight board insulating sheet 2

17 0000-10-11072 Converter DC-AC12VDC/700Vrms 1

18 9901-10-23920 Conducting foam 0501080 0.8

19 0000-10-10996 Leaf 92-047 1

20 042-000575-00 Screen mounting plate 1

21 M6T-030003--- Conducting foam, 4105AB51K 4

021-000043-00 or

0000-10-11069

(optional )

17”LCD screen 1

23 6800-20-50206 Screen support 3(for 17” anit-glare screen) 1

24 6800-20-50336 Anti-glare screen 1

25 6800-20-50392 PC cusion 4 1

26 6800-20-50391 PC cusion 3 1

27 M04-003105--- Tapping screw PT3×8 3

28 115-001326-01

T8 button board (anti-glare/optical encoder)

(without shank)

29 6800-20-50198 Silicon buttons 1

30 M6T-040001--- Clamp spring.1707P 1

31 0651-20-76735 Knob (mould MR76734) 1

32 042-000693-00 Knob mounting plate 1

33 0000-10-10789 Optical Encoder 16 steps 5VDC Dip6 1
