6-10
SN P/N Description Qty
15 6800-20-50691 Insulating strip for alarm LED board 1
16 6800-30-50086 Alarm LED board 1
17 6800-20-50389 Light conduction block 1 1
18 6800-20-50199 Alarm LED cover 1
19 6800-20-50390 Light conduction block 2 1
20 043-003871-00 Front bezel (T9) 1
21 048-003353-00 Touchscreen waterproof strip 2 2
22 048-003352-00 Touchscreen waterproof strip 1 2
23 021-000135-00 Touchscreen, resistance-type, 19″ 1
24 049-000346-00 Touchscreen, location block, 12″ 9
25 048-003351-00 19" touchscreen underlay 2 2
26 048-003350-00 19" touchscreen underlay 1 2
27 042-009882-00 19"right fixing bracket 1
28 6800-30-50082 Touchscreen control board 1
29 M04-004012--- Crosshead screw M3×6 32
30 009-003866-00 Cable for alarm lamp board 1
31 009-003867-00 Flat wire (T9) 1
32 009-003868-00 Cable for backlight board 1
33 6800-20-50450
Cable for connecting button board and main
board
1
34 009-000248-00
Cable for connecting new backlight board and
button board (AU)
1
35 6800-20-50157 Touchscreen control board cable 1
36 6800-20-50159 Power switch & LED board cable 1
37 M6G-020015--- Hose, 0.47 m 550mm
38 9901-10-23920 Conducting foam 870mm
39 M6T-030003--- Conducting foam, 4105AB51K 80mm
To Next Page
