SN P/N Description Qty
10 6800-20-50226 Dust-proof pad 5 2
11 6800-20-50205 Screen support 2(for 17” touchscreen) 1
12 6800-20-50232 Backlight board 1
13 M04-004012--- Crosshead screw M3×6 22
14 0000-10-11072 Backlight board 1
15 M04-002505--- Crosshead screw M3×6 2
16 6800-20-50692 Backlight board insulating sheet 2
17 6800-20-50671 Backlight board shield 1
18 0000-10-10996 Berylium-bronze leaf 92-047 1
19 9901-10-23920 Conducting foam0501080 2
20
6800-30-50082 or
6800-30-51095
(optional)
Touchscreen control board
（6800-30-51095 only used together with the
optional touchscreen 0000-10-10748）
1
21 042-000575-00 Screen mounting plate 1
22 M6T-030003--- Conducting foam, 4105AB51K 4
23
021-000043-00 or
0000-10-11069
(optional)
LCD screen 1
24 6800-20-50204 Screen support 1(for 17’ touchscreen) 1
25 6800-20-50225 Dust-proof pad 4 2
26 6800-20-50224 Dust-proof pad 3 1
27 6800-20-50142 Touchscreen waterproof strip 1
28 M04-003105--- Tapping screw PT3×8 3
29 115-004216-00
T8 button board (touchscreen/optical encoder)
(without shank)
1
30 6800-20-50198 Silicon buttons 1
31 M6T-040001--- Clamp spring.1707P 1
32 0651-20-76735 Knob (mould MR76734) 1
33 042-000693-00 Knob mounting plate 1
34 0000-10-10789 Optical Encoder 16 steps 5VDC Dip6 1
