Mindray BeneView T6 Service Manual

6-14
SN P/N Description Qty
13 6800-20-50686 Dust-proof pad 9 1
14 6800-20-50687 Dust-proof pad 10 1
15 6800-20-50239 Light shield 1
16 6800-20-50209 Screen support 6 1
17 M04-051001-01 Crosshead screw M3×4 4
18 6800-20-50232 Backlight board 1
19 M04-004012--- Crosshead screw M3×6 26
20 6800-20-50692 Backlight board insulating sheet 2
21 6800-20-50671 Backlight board shield 1
22 M04-002505--- Crosshead screw M3×6 2
23
0000-10-10750 or
0000-10-11073（optional ）
Backlight board 1
24 0000-10-10996 Berylium leaf 92-047 1
25 9901-10-23920 Conducting foam.0501080 2
26
6800-30-50082 or
6800-30-51095 (optional)
Touchscreen control board
（6800-30-51095 only used together
with optional touchscreen
0000-10-10748）
1
27 042-000575-00 Screen mounting plate 1
28 M6T-030004--- Conducting foam 4
29
0000-10-10753 or
0000-10-11068 (optional)
15” LCD （0000-10-11068 only used
together with optional inverter
0000-10-11073）
1
30 6800-20-50208 Screen support 5 1
31 6800-20-50688 Dust-proof pad 11 1
32 6800-20-50689 Dust-proof pad 12 1
33
6800-20-50179 or
043-004069-00
LCD fixed plate 2 6
34 6800-20-50142 Touchscreen waterproof strip 1
35 6800-20-50224 Dust-proof pad 3 1
36 M04-003105--- Tapping screw PT3×8 3
37 115-004218-00
T6 button board(touchscreen/optical
encoder) (without shank)
1
38 042-000693-00 Knob encoder mounting board 1
39 M6T-040001--- Clamp spring.1707P 1
40 0651-20-76735 Knob (mould MR76734) 1
