Mindray BeneView T6 Service Manual

3-57
ECG performance test
ECG waves are displayed correctly without noise and the HR
value is within 80±1 bpm.
ECG Lead Off alarm behaves correctly.
Paced signals are detected and pace pulse marks are displayed
when [Paced] is set to [Ye s ]
The difference between the amplitude of the ECG calibration
square wave and that of the wave scale is not greater than 5%.
Resp test
The Resp wave is not distorted and the Resp value is within
40±2 rpm.
SpO
2
test
Measure SpO
2
on a healthy person’s finger and a Pleth wave
and PR value are displayed. The displayed SpO
2
value is
within 95%-100%
NIBP test
The difference is within ±3 mm when 0, 50 or 200 mmHg is
set for NIBP accuracy test.
There is no leakage with NIBP, or the manual leakage test
result does not exceed 6mmHg/min.
Temp test
The value displayed for each Temp channel of the monitor is
within 37±0.1ºC.
IBP test
The static pressure value displayed for each IBP channel is
within 200±2 mmHg.
The ART and LV waves for each IBP channel are displayed
correctly.
C.O. test
The TB value displayed on the monitor is within 37±0.1ºC.
The displayed C.O. value is within 5±0.25L/min.
Mainstream CO
2
test
The mainstream CO
2
is zeroed successfully and the waveform
baseline recovers to zero.
CO
2
Apnea alarm behaves correctly.
The displayed CO
2
value is within 6±0.05％.
