3-59
The amplitude of electrical level at the signal output port of
MAP, CVP and SpO
2
are 5±0.25V, 5±0.25V and 10±0.5V
respectively.
PiCCO test
The detected catheter type accords with the setting of the
Pulsion Calbox, and the measurement errors of TB and TI are
within ±0.1℃.
The displayed static pressure values of pArt and pCVP are no
more than (200±2) mmHg.
The waveforms of pArt and pCVP are displayed correctly.
ScvO
2
test
The accuracy of ScvO
2
measurements is (50±3)% and (80±
3)%.
NMT test
The measurement of [PK-PK] is between 54V and 66V. The
The measurement of [+Width] is between 270us to 330us.
The message “Test passed. The function of NMT sensor is
OK” is presented if sensor check completes successfully.
EEG test
The result of sensor check is pass, and EEG measurements are
displayed on the monitor.
Nurse call relay performance test
The relay contacts are close when an alarm occurs.
Analog output performance test
The waves displayed on the oscillograph are identical with
those displayed on the monitor.
Electrical safety tests
Refer to A Electrical Safety Inspection. All the electrical
safety tests should be passed.
Touchscreen calibration
The touchscreen is calibrated successfully.
Recorder check
The recorder can print ECG waves correctly and the printout is
clear.
