Mindray BeneView T6 Service Manual

4-5
Power supply failure 1. Check if the voltage between two contact screws
in any slot reaches 12V DC. If yes and the
parameter module functions, the PCB assembly in
SRM might fail.
2. If there is no 12 V sent to the SMR, check that
the power module output voltage to the USB
interface board reaches 12V. If yes, the fuse on the
USB interface board might blow. Replace the USB
interface board.
Cable defective or
poorly connected
1. Check that the cable between SMR interface
board and communication board is properly
connected.
2. Check that connecting cables and connectors are
not damaged.
Nios II module loose or
failure
1. Check that Nios II module is correctly plug ed
2. If the symptom persists, replace the Nios II
module.
SMR interface board
failure
Replace the SMR interface board.
SMR communication
board failure
Replace the SMR communication board.
USB interface board
failure
Replace the USB interface board.
Mother board failure Replace the mother board.
Integral module rack
Module failure Replace parameter module. If a new module is
identified, the original one is defective.
Cable defective or
poorly connected
1. Check that the cables from 3-slot module rack
communication board to MPM module rack
communication board, module rack to mother board
are properly connected.
2. Check that connecting cables and connectors are
not damaged.
Wrong communication
board software revision
Upgrade the program of the module or Integral
module rack.
Integral module
rack cannot
identify
parameter
modules
Module (in some slots)
unrecognized
Replace the corresponding module rack
communication board.
