9
BeneVision N22/N19/N17/N15/N12
Quick Reference Guide
d. Select the Main Menu quick key or to return to the main display.
ECG
Adjust ECG Lead
The N Series bedside monitor allows the clinician to adjust the leads being
viewed on the main display. To adjust the ECG Lead:
a. Select the ECG numeric area or waveform area to enter the ECG dialog.
b. Select the Setup tab.
c. Set Lead Set according to the lead type you will be used.
d. Select ECG1 to adjust first lead.
e. Repeat step d or remaining displayed leads.
f. Select the Main Menu
quick key or to return to the main display.
Enable Pacemaker Detection
The N Series bedside monitor allows the clinician to enable pacemaker detection.
The
symbol is displayed when the pacemaker detection is enabled.
To enable the pacemaker detection on the N Series bedside monitor:
a. Select the ECG numeric area or waveform area to enter the ECG dialog.
b. Select the Pacer tab.
c. Set Paced to Yes .
d. Select the Main Menu
quick key or to return to the main display.
Initiate ECG Relearn
To initiate ECG relearning manually on the N Series bedside monitor:
a. Select the ECG numeric area or waveform area to enter the ECG dialog.
b. Select Relearn at the bottom left corner of the dialog.
c. Select the Main Menu
quick key or to return to the main display.
Init
iate ST Analysis
To initiate ST analysis on the N Series bedside monitor:
a. Select the ECG numeric area or waveform area to enter the ECG dialog.
b. Select the ST tab
.
To Next Page
