24
BeneVision N22/N19/N17/N15/N12
Quick Reference Guide
the main display.
• EWS (Optional): Split screen with EWS scoring tool on left side of display
with real time waveform and numeric parameters on the main display.
c. Select the Main Menu
quick key or to return to the main display.
Note1: The first waveform is always an ECG lead and HR is always located in the
first digital tile in the Normal Screen selection.
Note2: Digital and waveform display selections on the N Series bedside monitor
and Central Monitoring System are independent.
REVIEW
Tabular Trends
To display Tabular trends on a patient:
a. Select Review
quick key, or select the Main Menu quick key.
b. Select Tabular Trends tab from the Review column.
c. Select Trend Group and specify trend category or select Custom for user
defined parameters to be displayed.
d. Select Interval to specify the time interval tabular trends are to be
displayed.
e. Select the Main Menu
quick key or to return to the main display.
To record Tabular trends on a patient on the N Series bedside monitor to the
integrated or independent recorder:
a. Select Review
quick key, or select the Main Menu quick key.
b. Select Tabular Trends tab from the Review column.
c. Select
and confirm specified time period.
d. Select Record to print to the integrated recorder.
e. Select the Main Menu
quick key or to return to the main display.
To print Tabular trends on a patient on the N Series bedside monitor to the
printer:
a. Select Review
quick key, or select the Main Menu quick key.
b. Select Tabular Trends tab from the Review column.
To Next Page
