29
BeneVision N22/N19/N17/N15/N12
Quick Reference Guide
d. Select the Main Menu quick key or to return to the main display.
Or
a. Select ECG waveform or ECG numeric tile to enter ECG dialog.
b. Select Setup tab.
c. Select QRS Volume.
d. Select volume ranging from 0-10 (0=Off 10=Max)
e. Select the Main Menu
quick key or to return to the main display.
Or
a. Select SpO
2
waveform or SpO
2
numeric tile to enter SpO
2
dialog.
b. Select PR Setup tab.
c. Select QRS Volume.
d. Select volume ranging from 0-10 (0=Off 10=Max).
e. Select the Main Menu
quick key or to return to the main display.
* The minimum volume range (X) is configurable.
Note: The QRS tone is derived from either the HR or PR, depending on which is
the selected source of the QRS tone. When monitoring SpO
2
, there is a variable
pitch tone changes as the patient’s saturation level changes. The pitch of the
tone rises as the saturation level increases and falls as the saturation level
decreases.
DATE AND TIME
The N Series bedside monitor allows the clinician to adjust the date and time if the
N Series bedside monitor is not connected to the network. To adjust the system
time, date, and format:
a. Select the Main Menu
quick key and select Time from the System
column.
b. Set Date and Time.
c. Set Date Format.
d. Enable 24 Hour Time if desired.
e. Enable Daylight Saving Time if desired.
To Next Page
