31
BeneVision N22/N19/N17/N15/N12
Quick Reference Guide
Menu quick key if the touchscreen is disabled.
To manually unlock the touchscreen, hold and press the Main Menu quick key
and slide to the right as directed by the arrow.
The touchscreen can be unlocked automatically when the lock period is over if
enabled. To set a preconfigured lock period,
a. Select the Screen Setup
quick key, and select the Display tab.
Or
a. Select the Main Menu
quick key, and select Display from the Display
column.
b. Select Screen Lock Duration and set duration from drop down list.
c. Select the Main Menu
quick key or to return to the main display.
PAIR THE TM80 TELEMETRY MONITOR
Pair the TM80
The N Series bedside monitor allows the TM80 telemetry pack to be displayed on
the main screen when they are paired.
To pair the TM80 with the N Series bedside monitor,
a. Select the Main Menu
quick key.
b. Select Wireless Module, if detected, from the Parameters column.
c. Select the desired TM80 under the Device Name column. If the desired
TM80 is not displayed, select Update List.
d. Select Add adjacent to the desired TM80.
e. Select
• Continue Patient in Monitor to use the patient information and
parameters settings from the monitor.
• Continue Patient in Telemetry to use the patient information and
parameters settings from the TM80 and CMS.
f. Select the Main Menu
quick key or to return to the main display.
Unpair the TM80 Telemetry Monitor from the N Series Bedside Monitor
To unpair the TM80 and the N Series bedside monitor:
