P/N: 046-017383-00 Rev1.0
11
BeneVision TM80 Quick Reference Guide
RESP (OPTIONAL)
Set NCM Alarm Delay
The TM80 allows configuring the desired time for NCM Alarm Delay. When
the patient has stopped breathing for longer than the set NCM Alarm Delay
time, the TM80 will trigger the "No Chest Movement" alarm.
To set NCM Alarm Delay:
• On the main screen, tap the Resp digital area or Resp waveform area to
enter the Resp menu.
OR
1. Press to enter the main menu.
2. Tap Parameter Setup.
3. Tap Resp.
4. Set NCM Alarm Delay.
Note: The "No Chest Movement" alarm is displayed on the Central Monitoring
System only.
Note: The Resp functionality for the TM80 telemetry monitor is available at the
CMS whose version is 03.00 and above only.
SpO2 (OPTIONAL)
The TM80 allows continuous pulse oximetry.
Connect the SpO2 Module
Connect the SpO2 module to the TM80 as shown in the following figure.
