BeneVision TM80 Quick Reference Guide
TM80 PHYSICAL VIEW
1. Display Activation (Power On/Off ) key
When the TM80 is powered off
• Pressing this key will turn the TM80 on.
When the TM80 is powered on
• And the screen display is on, pressing this key will turn the display off.
• And the screen display is off, pressing this key will turn the display on.
• Press and hold this key for two seconds to display the power off
confirmation menu.
Note: When the TM80 is disconnected from the Central Monitoring System
(CMS), its display is always on. You cannot turn it off.
2. Nurse Call key
Nurse call key activates nurse call message at the CMS.
3. Main Menu key
• Pressing this key when on the main screen will open the main menu.
• Pressing this key when a menu is open will return to the main screen.
• Pressing this key when the display is off will turn the display on.
5
4
3
1 2
6 8
7
9
10
