2-8 System Overview
No. Name Function
1. Monitor
Displays the images and parameters during
scanning.
(Support optional 15-inch or 17-inch monitor or 19-
inch monitor)
2. Speaker Sound output.
3. Touch screen panel Operator-system interface or control.
4. Ultrasound gel holder Used for placing the ultrasound gel.
5. Probe holder
Used for placing the general probe (not including pencil
probe or intra-cavity probe).
6. Pencil probe holder Used for placing the pencil probe.
7. Probe cable hook Used for fixing the probe cable.
8. Keyboard Used for typing characters or entering some functions.
9. Main control panel Operator-system interface or control.
