System Preparation 3-11
Function setting
The function of the footswitch can be set, for details, please refer to “12.1.6 Key
Configuration”.
3.6.3 Graph /Text printer
3.6.3.1 Connecting a Local Printer
As shown in the figure below, a graph / text printer has a power cord and data cable. The
power cord shall be directly connected to a wall receptacle as required.
1. Connect the data cable with the USB port on the ultrasound system.
2. Plug the other end power plug into an appropriate outlet.
3. Power on the system and the printer.
4. Check the printer status:
z Enter [Setup]Æ[Print Preset]Æ“Printer Driver” page, printers that are installed
automatically will be displayed in the list with the “Status” of “Ready”.
Data cord
USB port
Power cord
USB port
