UA-66 Urine Analyzer Operator’s Manual
-15-
“Options>Printer” menu:
Options>Printer
Option
Shade
Diagnosis
Figure 3.9
Use ▲ and ▼ to select “Auto Print”, press START to modify the auto print option:
Options>Printer>Option
Not Print
Print
Figure 3.10
Press ▲ and ▼ to select “Yes” or “No”, press START to validate the new option. If “Yes” is
selected, the instrument will print a report after a urine sample was tested.
At the “Option>Printer” menu( see Figure 3.3 ), use ▲ and ▼ to select “Shade”, press START to
modify the print shade:
Figure 3.11
A bar shows the relative value of the print shade. Press ▲ to increase the shade and ▼ to
decrease the shade. Press START to validate the new value.
The print shade varies in different seasons. In cold seasons, the print shade should be set to
higher values. In warm seasons, the print shade should be set to lower values.
3.6 RS-232C
The instrument equipped a RS-232C serial port for communication with a host computer. The
“Options>Serial Port” menu is used to set the baud rate of the serial port. At the “Options”
menu( See Figure 3.1 ), use
▲ and ▼ to select “Serial Port”, press START to select the baud rate:
